CELLTRON™ Advantage Digital
CELLTRON™ Advantage Digital
The CELLTRON™ Advantage Digital is a fast, user-friendly, premium handheld tester for measuring battery conductance, voltage, temperature and strap resistance in high-noise environments for a complete battery state-of-health analysis.
The Advantage Digital delivers a complete battery state-of-health analysis that uploads wirelessly to the web-based UNITE™ database for centralized storage, proactive maintenance planning, and compliance reporting.
Measures conductance, voltage, temperature & strap resistance
Tests VRLA, VLA, and NiCad battery types
Professional-grade tester, probes, and accessories
Measures battery voltage down to one (1) volt
Simplified string configuration pre-programming via laptop
Wireless data upload/download via web-based UNITE™ software
Dual-microprocessor architecture for high-noise immunity
Edge Rejection digital signal filtering for clean, accurate readings
Fast-acting safety protection relay shields both device and user
Up to 8 hours of testing per battery charge
Conductance-based diagnostics, noise immunity, and wireless data transfer, engineered for reliable field testing.
Accurate Conductance Testing
Conductance-based diagnostics deliver a highly accurate, reliable predictor of a battery’s end of life. Edge Rejection technology filters anomalies at the start and end of each sample for cleaner, more precise readings.
Faster Testing Times
Just connect the two test leads (by clamp or lighted probe) to the positive and negative posts and test in a matter of seconds.
Wireless Communication
Built-in Wi-Fi moves data to and from the tester with no additional cards, cords, or hardware required.
High Noise Immunity
A powerful dual-microprocessor architecture stands up to the high-noise UPS / switching environments that cause other testers to fail.
Device & User Protection
A fast-acting relay responds in milliseconds to any input above 23.3 volts, instantly protecting both device and user.
Every CELLTRON™ Advantage Digital ships fully loaded with a suite of onboard testing, customization, and data-management tools.
BATTERY TEST
Standard, conductance-based battery testing.
DATA MANAGER
Upload, download, and delete testing data.
BATTERY MANAGER
Select from a library of pre-loaded battery manufacturers and types.
REPORTS
Generate reports for individual battery string results.
THRESHOLDS
Set tester thresholds for voltage, conductance, and temperature.
QUICK TEST
Start a test on a single cell or monoblock without setting up a site.
FAVORITE SETUP
Set up favorites for quick access.
AUTOSTART
Set the tester to activate a test process on contact.
SITE TRENDING
Effective trend analysis including test comparisons in one screen.
CAPACITY MANAGER
Record cell voltages on a timed interval during a capacity load test.
GEN START
Test the state of health of generator starting batteries.
DIGITAL MULTIMETER
Accurately measure a battery’s DC or AC voltage.
Next generation features that make the CELLTRON™ Advantage Digital one of the most robust testers available.
Integrated IR Temperature Measurement
Captures battery temperature without contact during test
USB Communication Ports
Export to a USB drive, import configurations, or connect to a PC
Light-Up Probes & Clamps
Internal LEDs light hard-to-see battery posts in dark spaces
Quick-Connect “Y” BNC Cable
Easily swap between probes and clamps in seconds
8-hour Rechargeable Battery Pack
A full day of testing; recharges in or out of the tester
Rapid Battery Testing
Connect two leads, by clamp or probe, and capture a full battery assessment in seconds, even in the high-noise environments that cause other testers to fail.
Pre-Program on a Laptop
Pre-program battery string configurations on a laptop via the UNITE™ software and wirelessly upload to the tester, eliminating manual input errors and saving valuable time on-site. Setups can be saved and shared across testers.
Faster Testing Time
Testing is carried out in a matter of seconds, simply by connecting the two test leads to the battery’s positive and negative posts. Light-up probes and clamps illuminate hard-to-see terminals.
Access Your Testing Data
Monitoring battery performance is only valuable when the data reaches the right people. The CELLTRON™ Advantage Digital gets it there, wirelessly, before you leave the site.
Wi-Fi Connection
Test data and tester configurations transfer wirelessly between the handheld and the UNITE™ software. No cards, cords, or extra hardware.
USB 2.0 Ports
Export test data to a USB drive, import a tester configuration from a USB drive, or connect the tester directly to a PC.
Portable Thermal Printer
Print reporting data on the spot with the rechargeable, battery-powered thermal printer - ideal for handing off results in the field.
The UNITE™ software provides centralized data storage for an entire network of battery plants, enabling analysis and reporting from a centralized location.
Centralized battery monitoring and testing data
Wireless data uploads from handheld testers
Historical timelines of battery data
Configurable threshold alarms & warnings via email / text
Generate string report downloads at the click of a button
Highly customized report template creation and archive
Flexible user roles for customizable, tiered levels of access
Highly-secure, hosted on the Microsoft® Azure® cloud
Visualize your entire plant network geographically in a single map view. Visually confirm the status of all plants and quickly key in on those that may require attention or maintenance.
All strings, devices, and batteries within a plant can be viewed in a single dashboard. Get quick access to any alarms or warnings as well as consolidate string performance information.
Review the status of a specific string with the ability to drill into key performance information on individual batteries. View details on discharge events and generate a sting report with a single click.
Dive into the present and historical data of individual batteries within a string. Visualize key battery performance indicators and trending data to pinpoint batteries in need of replacement with accuracy.
Choose from several CELLTRON™ Advantage Digital kit bundles, each configured to have your team field-ready for testing from day one. Each kit ships complete in a ballistic-nylon backpack with custom inserts, so the tester, cables, probes, clamps, and chargers travel together and arrive ready to test.
- CELLTRON™ Advantage Digital
- Belt loop
- Battery pack (2)
- Universal charger
- USB A/B cable
- Backpack
- 4' interchangeable cable
- 8' probe cable
- Probe set
- Spear probe tip replacements
- Clamp set
- Waffle probe tip replacements
- Probe extender for 8' probe cables
- Probe extender for 4' probe cables
- Free 90-day UNITE™ trial
The UNITE™ reporting engine goes beyond basic reporting and offers a robust, customizable reporting system that addresses a wide range of assets technicians inspect. Users can generate detailed reports that incorporate battery metrics along with data from other inspected components.
Customizable branding with logos, company info, and tester details
Automated inspection alarms and warnings summary
Automated summary of inspection activities for quick review
Select from a list of pre-populated common testing activities
Create custom activity checklists for tailored reporting
Incorporate inspection pictures for visual context
Save and share frequently used templates within your organization
Deliver professional reports that convey actionable insights
Components & Dimensions
1. LCD display
2. Tester body
3. Glove-compatible key pad
4. Port access door
5. USB Type-A Port (data storage/transfer)
6. USB Type-B Port (PC connection)
7. DC barrel charging port
8. Probe/clamp cable port
9. Temperature sensor
10. IR communications LED (printer)
11. Rechargeable battery pack
12. Side vent
13. Rear vent
14. Rubber handle grip
15. Probe testing interface
16. Piranha clamp testing interface
17. Integrated light
18. BNC cable port
Specifications
Voltage Range
-
0.8 - 23.5 VDC
Conductance Range
-
100 - 19,990 Siemens
(Conductance testing voltage range 1V to 23.3 VDC. Battery should be fully charged for best results.)
Test Data Storage
- 50 string locations of 240 test results
- Stored internally
- Unlimited transfer to USB drive
Accuracy
-
+/-2% across test range, voltage & conductance
Voltmeter Resolution
-
5 mVDC
User Programmable Functions
- Preset values for over 250 battery types
- Low voltage alarm setting
- Low conductance warning
- Low conductance failure
- Test mode (pushbutton/auto start)
Cable Options
- Dual contact clamps
- Dual contact probes
- Custom cables by quotation
Power Requirements
- 7.2V, 2300mAh, NiMH
- Internal swappable battery & charger
LCD Display
- 2.97 in x 2.81 in (75.4 mm x 71.3mm)
- 128 x 128 pixels
- 40 degree viewing angle
- LED backlight
Keypad
- Alpha-numeric
- Stainless-steel dome
- Polycarbonate overlay
- 1,000,000 actuations
Data Transfer
- Wi-Fi
- USB 2.0 Flash Drive (Type-A)
- USB 2.0 PC Interface (Type-B)
- Half-duplex IrDA protocol for optional printer
Environmental Operating Range
- 0 to +104°F (0 to +40°C)
- 95% relative humidity
- Non-condensing
Storage Temperature
-
-4 to 180°F (-20 to 82°C)
Enclosure Rating
-
IP20
Over Voltage Protection
- Auto-reset disconnect
- Reverse polarity protected
Housing Material
- Acid-resistant ABS plastic
- Santoprene™ overmold
Housing Material
-
11in x 4in x 3in (279mm x 105mm x 80mm)
Tester Weight
-
2.6 lb (1 Kg)
Languages
- English
- Spanish
- German
- Polish
- Portuguese
- Dutch
- Russian
- French
- Italian
- Chinese
- Japanese
BASIC KIT
| Model | Description |
|---|---|
| CADD-5000 KIT | CELLTRON™ Advantage Digital 5000 basic battery testing kit |
Included in the kit
- CELLTRON™ Advantage Digital
- (1) Battery pack (CA090)
- Universal charger (CA091)
- Backpack (CA100)
- 3.3 ft (1 m) USB A/B cable (CA049)
- USB 2.0 4GB drive (CA089)
- Free 90-day UNITE™ trial
COMPLETE KIT
| Model | Description |
|---|---|
| CADD-5200 KIT | CELLTRON™ Advantage Digital 5200 enhanced battery testing kit |
Included in the Kit
- CELLTRON™ Advantage Digital
- (2) Battery pack (CA090)
- Universal charger (CA091)
- 3.3 ft (1 m) USB A/B cable (CA049)
- Backpack (CA100)
- Probe / clamp cable (CA026)
- Probe set (CA093)
- Probe tip replacements (CA069 / CA031)
- Piranha clamp set (CA092)
- USB 2.0 4GB drive (CA089)
- Free 90-day UNITE™ trial
ENHANCED KIT
| Model | Description |
|---|---|
| CADD-5500 KIT | CELLTRON™ Advantage Digital complete battery testing kit |
Included in the Kit
- CELLTRON™ Advantage Digital
- (2) Battery pack (CA090)
- Universal charger (CA091)
- 3.3 ft (1 m) USB A/B cable (CA049)
- Backpack (CA100)
- Probe / clamp cable (CA026)
- Probe set (CA093)
- Probe tip replacements (CA069 / CA031)
- Piranha clamp set (CA092)
- USB 2.0 4GB drive (CA089)
- 8 ft (2.44 m) probe cable (CA025)
- Probe extenders for 8 ft cable (C034)
- Probe extenders for 4 ft cable (CA034)
- Free 90-day UNITE™ trial
ACCESSORIES & REPLACEMENT PARTS
RED LIGHTED PROBE
| Model | Description |
|---|---|
| CA093R | Red 6” lighted probe |
- 6 in (152 mm) probe with rotating head and 0.5 in (13 mm) tip for instant contact
- Designed with an internal LED to light hard to see battery posts
- Quick connect/disconnect BNC connector for easy removal
- Pre-installed dual gold-plated over Duralloy® waffle probe tips
BLACK LIGHTED PROBE
| Model | Description |
|---|---|
| CA093B | Black 6” lighted probe |
- 6 in (152 mm) probe with rotating head and 0.5 in (13 mm) tip for instant contact
- Designed with an internal LED to light hard to see battery posts
- Quick connect/disconnect BNC connector for easy removal
- Pre-installed dual gold-plated over Duralloy® waffle probe tips
RED & BLACK LIGHTED PROBE
| Model | Description |
|---|---|
| CA093 | (1) red and (1) black 6” lighted probe |
- 6 in (152 mm) probe with rotating head and 0.5 in (13 mm) tip for instant contact
- Designed with an internal LED to light hard to see battery posts
- Quick connect/disconnect BNC connector for easy removal
- Pre-installed dual gold-plated over Duralloy® waffle probe tips
REPLACEMENT PROBE TIPS
| Model | Description |
|---|---|
| CA069 | Replacement probe tips (4 probe tips, 2 probe caps) |
| CA031 | Replacement probe waffle tips (4 probe tips) |
- Replacement gold-plated over Duralloy® dual probe tips
RED LIGHTED PIRAHNA CLAMP
| Model | Description |
|---|---|
| CA092R | Red 6.5” piranha lighted clamp |
- 2” opening to attach to large battery terminals
- Designed with an internal LED to light those hard to see battery posts in dark places
- Quick connect/disconnect BNC connector for easy removal
BLACK LIGHTED PIRAHNA CLAMP
| Model | Description |
|---|---|
| CA092B | Black 6.5” piranha lighted clamp |
- 2” opening to attach to large battery terminals
- Designed with an internal LED to light those hard to see battery posts in dark places
- Quick connect/disconnect BNC connector for easy removal
RED & BLACK LIGHTED PIRAHNA CLAMPS
| Model | Description |
|---|---|
| CA092 | (1) red and (1) black 6.5” piranha lighted clamps |
- 2” opening to attach to large battery terminals
- Designed with an internal LED to light those hard to see battery posts in dark places
- Quick connect/disconnect BNC connector for easy removal
8' PROBE CABLE
| Model | Description |
|---|---|
| CA025 | 8’ CELLTRON Advantage probe cable |
- Flex strain relief and spread of 48” with “Y” junction, for 6 and 12 Volt batteries only
- 6" rotating heads and half inch tips for instant contact
- Replaceable gold-plated over Duralloy® dual probe tips
4' INTERCHANGEABLE CABLE
| Model | Description |
|---|---|
| CA026 | 4’ interchangeable CELLTRON Advantage cable |
- Flex strain relief and spread of 24” with “Y” junction
- Incorporates a quick connect/disconnect radio frequency BNC connector
for easy probe or clamp removal - Compatible with CA092 clamps and CA093 probes
30" PROBE EXTENDERS
| Model | Description |
|---|---|
| CA034 | 30” probe extenders |
- Soft rubber handles
- Utilized in hard-to-reach areas such as UPS cabinets
- Weight: 2 lbs
- CA034 are used with the CA026/CA093
30" LIGHTED PROBE EXTENDERS
| Model | Description |
|---|---|
| C034 | 30” lighted probe extenders |
| C033 | Replaceable optic lamp kit for probe extenders with adhesive tape |
- Soft rubber handles
- Utilized in hard-to-reach areas such as UPS cabinets
- Weight: 2 lbs
- C034 are used with the CA025, 8’ CELLTRON Advantage probe cable.
RECHARGEABLE BATTERY PACK
| Model | Description |
|---|---|
| CA090 | CELLTRON Advantage 7.2V NiMH rechargeable battery pack |
DESKTOP RAPID CHARGER
| Model | Description |
|---|---|
| CA096 | CELLTRON Advantage desktop rapid battery charger |
- For use with the CELLTRON Advantage battery pack CA090 with rated voltage of 7.2VDC
- Rapid charge to 80% of rated voltage in 1 to 2.5 hours, trickle charge the remaining voltage
- Automatically end charging with negative delta voltage greater than 50mVDC
- AC power adapter included with an input of 120-240VAC 50-60HZ and output of 12VDC 2.5Amp
UNIVERSAL IN-UNIT BATTERY CHARGER
| Model | Description |
|---|---|
| CA091 | CELLTRON Advantage universal in-unit battery charger |
- Input: 100 - 240 VAC (50/60 Hz) @ 14W
- Output: 9 VDC @ 700 mA
- Expected Battery: 4.8 - 7.2 VDC @ 1.2 - 12 Ah
39" USB A/B CABLE
| Model | Description |
|---|---|
| CA049 | CELLTRON Advantage 39” USB A/B cable |
- For USB 2.0 communication between a PC and the CELLTRON Advantage
4GB USB FLASH DRIVE
| Model | Description |
|---|---|
| CA089 | 4GB USB 2.0 drive for use with CELLTRON Advantage |
- Export test data from the tester on to the USB drive or import tester
configuration from the USB drive to the tester
THERMAL IR / RS232 PRINTER
| Model | Description |
|---|---|
| CA087 | Thermal IR / RS232 printer for use with CELLTRON™ Advantage |
- Power adapter and 4 NMH rechargable AA batteries included
- Weight: 1 lb
- Dimensions: 2.25"H X 75"L X 3.25"W
PRINTER POWER ADAPTER / CHARGER
| Model | Description |
|---|---|
| A090 | Power adapter / charger for CA087 thermal IR / RS232 printer |
THERMAL PRINTER PAPER
| Model | Description |
|---|---|
| A095 | 6 pack thermal printer paper rolls |
CUSTOM BACKPACK
| Model | Description |
|---|---|
| CA100 | CELLTRON™ Branded Ballistic Nylon Backpack |
- Customized inserts fitted for the Celltron Advantage and Ultra handheld testers as well as accessories
- Backpack only, tester and accessories sold separately
